Fixed Inductors
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
22R475MCFIXED IND 4.7MH 100MA 13.2OHM SM Murata Power Solutions Inc. |
804 | 0.84 |
|
Datasheet |
2200RM | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 4.7 mH | ±10% | 100 mA | - | Unshielded | 13.2Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.311" (7.90mm) |
|
|
22R226MCFIXED IND 22MH 44MA 82.5 OHM SMD Murata Power Solutions Inc. |
381 | 1.71 |
|
Datasheet |
2200RM | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 22 mH | ±10% | 44 mA | - | Unshielded | 82.5Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.311" (7.90mm) |
|
|
22R336MCFIXED IND 33MH 37MA 110 OHM SMD Murata Power Solutions Inc. |
4,285 | 1.71 |
|
Datasheet |
2200RM | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 33 mH | ±10% | 37 mA | - | Unshielded | 110Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.311" (7.90mm) |
|
49680SCFIXED IND 68UH 2A 143 MOHM SMD Murata Power Solutions Inc. |
960 | 1.77 |
|
Datasheet |
4900S | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | Wirewound | - | 68 µH | ±20% | 2 A | - | Shielded | 143mOhm Max | 47 @ 1MHz | 7MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.480" L x 0.480" W (12.20mm x 12.20mm) | 0.315" (8.00mm) |
|
|
49681SCFIXED IND 680UH 620MA 1.2OHM SMD Murata Power Solutions Inc. |
372 | 0.70 |
|
Datasheet |
4900S | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | Wirewound | - | 680 µH | ±20% | 620 mA | - | Shielded | 1.2Ohm Max | 27 @ 800kHz | 3MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.480" L x 0.480" W (12.20mm x 12.20mm) | 0.315" (8.00mm) |
|
12LRS105CFIXED IND 1MH 400MA 2.3 OHM TH Murata Power Solutions Inc. |
722 | 0.71 |
|
Datasheet |
1200LRS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 1 mH | ±15% | 400 mA | - | Shielded | 2.3Ohm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
22R686CFIXED IND 68MH 18MA 242 OHM TH Murata Power Solutions Inc. |
367 | 0.84 |
|
Datasheet |
2200R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 68 mH | ±10% | 18 mA | - | Unshielded | 242Ohm Max | 70 @ 50kHz | 200kHz | - | -25°C ~ 70°C | 1 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.413" (10.50mm) |
|
12RS223CFIXED IND 22UH 3.3A 42 MOHM TH Murata Power Solutions Inc. |
196 | 0.85 |
|
Datasheet |
1200RS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 22 µH | ±20% | 3.3 A | - | Shielded | 42mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
19R476CFIXED IND 47MH 110MA 36 OHM TH Murata Power Solutions Inc. |
1,807 | 1.57 |
|
Datasheet |
1900R | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 47 mH | ±10% | 110 mA | - | Unshielded | 36Ohm Max | - | - | - | -40°C ~ 95°C | 1 kHz | - | Through Hole | Radial Lead | 0.472" Dia (12.00mm) | 0.827" (21.00mm) |
|
15333CFIXED IND 33UH 5.08A 31.2MOHM TH Murata Power Solutions Inc. |
1,238 | 1.74 |
|
Datasheet |
1500 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 33 µH | ±10% | 5.08 A | - | Unshielded | 31.2mOhm Max | 107 @ 1MHz | 8MHz | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.661" Dia (16.80mm) | 0.839" (21.30mm) |
