IGBT Modules
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRG5K100HF06AIGBT MOD 600V 170A 405W POWIR 34 Infineon Technologies |
6,565 | 0.00 |
|
- |
- | POWIR® 34 Module | Box | Obsolete | - | Half Bridge | 600 V | 170 A | 405 W | 2.1V @ 15V, 100A | 1 mA | 6.2 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | POWIR® 34 |
|
|
FP35R12W2T7PBPSA1LOW POWER EASY Infineon Technologies |
3,918 | 0.00 |
|
- |
EasyPIM™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 35 A | - | 1.6V @ 15V, 35A | 5.8 µA | 6.62 nF @ 25 V | Three Phase Bridge Rectifier | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | AG-EASY2B |
|
FS75R07W2E3B11ABOMA1IGBT MODULES Infineon Technologies |
2,847 | 0.00 |
|
- |
EasyPACK™ | Module | Tray | Last Time Buy | Trench Field Stop | Three Phase Inverter | 650 V | 95 A | 275 W | 1.9V @ 15V, 75A | 50 µA | 4.6 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | ACEPACK™ 2 |
|
|
FP50R12W2T7PBPSA1LOW POWER EASY Infineon Technologies |
9,513 | 0.00 |
|
- |
EasyPIM™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 50 A | - | 1.6V @ 15V, 35A | 5 µA | 11.1 nF @ 25 V | Three Phase Bridge Rectifier | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | AG-EASY2B |
|
|
IRG5K100HF12AIGBT MOD 1200V 200A POWIR 34 Infineon Technologies |
3,576 | 0.00 |
|
- |
- | POWIR® 34 Module | Box | Obsolete | - | Half Bridge | 1200 V | 200 A | 620 W | 2.6V @ 15V, 100A | 1 mA | 12.9 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | POWIR® 34 |
|
|
FS75R12W2T4PBPSA1LOW POWER EASY AG-EASY2B-411 Infineon Technologies |
6,997 | 0.00 |
|
- |
EasyPACK™ | Module | Tray | Active | Trench Field Stop | Full Bridge Inverter | 1200 V | 107 A | 375 W | 2.15V @ 15V, 75A | 1 mA | 4.3 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | AG-EASY2B |
|
|
FS75R12W2T4PB11BPSA1LOW POWER EASY Infineon Technologies |
4,189 | 0.00 |
|
- |
* | - | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
DDB6U134N16RRB38BPSA1LOW POWER ECONO Infineon Technologies |
7,211 | 0.00 |
|
- |
- | Module | Tray | Active | - | Single Chopper | 1200 V | 70 A | 500 W | 2.75V @ 15V, 70A | 500 µA | 5.1 nF @ 25 V | Standard | Yes | 150°C (TJ) | Chassis Mount | AG-ECONO2B |
|
|
FS75R07N2E4BPSA1LOW POWER ECONO AG-ECONO2B-411 Infineon Technologies |
4,392 | 0.00 |
|
- |
EconoPACK™ 2 | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 650 V | 75 A | 250 W | 1.95V @ 15V, 75A | 1 mA | 4.6 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | AG-ECONO2B |
|
|
FP25R12N2T7B16BPSA1LOW POWER ECONO Infineon Technologies |
7,096 | 0.00 |
|
- |
TRENCHSTOP™ | Module | Tray | Active | Trench Field Stop | - | - | - | - | - | - | - | Standard | No | - | Chassis Mount | AG-EASY2B |
