SCRs - Modules
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DFA50BA80DIODE MODULE 800V 50A |
7,301 | 0.00 |
|
Datasheet |
- | Module | Active | Bridge, 3-Phase - SCRs/Diodes | 1 SCR, 6 Diodes | 800 V | 50 A | - | 3 V | 70 mA | 730A, 800A | - | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | |
|
VTO70-16IO7RECT BRIDGE 3PH 1600V FO-T-A |
2,186 | 0.00 |
|
Datasheet |
- | FO-T-A | Box | Obsolete | Bridge, 3-Phase - All SCRs | 6 SCRs | 1.6 kV | 70 A | - | 1.5 V | 100 mA | 550A, 600A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
CD420890BSCR MOD ISO DUAL 800V 90A |
6,581 | 0.00 |
|
Datasheet |
- | POW-R-BLOK™ Module | Bulk | Obsolete | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 800 V | 95 A | 150 A | 3 V | 150 mA | 2000A, 2100A | 250 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
CD421290BSCR MOD ISO DUAL 1200V 90A |
5,825 | 0.00 |
|
Datasheet |
- | POW-R-BLOK™ Module | Bulk | Obsolete | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.2 kV | 95 A | 150 A | 3 V | 150 mA | 2000A, 2100A | 250 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
MCNA120PD2200TBBIPOLAR MODULE - THYRISTOR TO-2 |
7,379 | 0.00 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 2.2 kV | 120 A | 190 A | 1.5 V | 100 mA | 2200A, 2380A | 150 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
|
T620023004DNSCR PHASE CTRL MOD 200V 300A |
9,420 | 0.00 |
|
Datasheet |
- | TO-200AB, A-PUK | Bulk | Discontinued at Digi-Key | Single | 1 SCR | 200 V | 300 A | 470 A | 3 V | 150 mA | 5000A, 5500A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount, 8" Wire Lead |
|
PWB80A30THYRISTOR MODULE 300V 80A |
6,966 | 0.00 |
|
Datasheet |
- | Module | Active | Bridge, 3-Phase - All SCRs | 3 SCRs | 300 V | 80 A | 125 A | 2 V | 150 mA | 2280A, 2500A | 100 mA | -30°C ~ 150°C (TJ) | - | - | Chassis Mount | |
|
|
PWB80A40THYRISTOR MODULE 400V 80A |
4,568 | 0.00 |
|
Datasheet |
- | Module | Active | Bridge, 3-Phase - All SCRs | 3 SCRs | 400 V | 80 A | 125 A | 2 V | 150 mA | 2280A, 2500A | 100 mA | -30°C ~ 150°C (TJ) | - | - | Chassis Mount | |
|
|
MT110CB18T1-BPTHYRISTOR MODULES,T1 |
7,942 | 0.00 |
|
Datasheet |
- | Module | Bulk | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.8 kV | 110 A | - | 3 V | 150 mA | 2250A @ 50Hz | 250 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
|
MCC94-20IO1BMOD THYRISTOR DUAL 2000V TO240AA |
8,008 | 0.00 |
|
Datasheet |
- | TO-240AA | Box | Active | Series Connection - All SCRs | 2 SCRs | 2 kV | 104 A | 180 A | 1.5 V | 100 mA | 1700A, 1800A | 150 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
VWO85-12IO1MODULE AC CTLR 3PH 1200V V2-PACK |
6,213 | 0.00 |
|
Datasheet |
- | Module | Box | Obsolete | 3-Phase Controller - All SCRs | 6 SCRs | 1.2 kV | 27 A | 59 A | 1.5 V | 100 mA | 520A, 560A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
MCD132-12IO1MOD THYRISTOR/DIODE 1200V Y4-M6 |
5,041 | 0.00 |
|
Datasheet |
- | Y4 | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.2 kV | 130 A | 300 A | 2.5 V | 150 mA | 4750A, 5080A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
CD431290BSCR MOD ISO DUAL 1200V 90A |
4,569 | 0.00 |
|
Datasheet |
- | POW-R-BLOK™ Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.2 kV | 95 A | 150 A | 3 V | 150 mA | 2000A, 2100A | 250 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
F1892SDK400MODULE SCR/DIODE 90A 120VAC |
5,722 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 400 V | - | - | 3 V | 150 mA | 1950A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MT160C08T2-BPInterface |
4,905 | 0.00 |
|
Datasheet |
- | Module | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 800 V | 160 A | - | 3 V | 150 mA | 5400A @ 50Hz | 400 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
|
T511FSMODULE POWER |
5,357 | 0.00 |
|
Datasheet |
- | Module | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
CD431699CSCR MODULE DUAL |
2,071 | 0.00 |
|
Datasheet |
- | POW-R-BLOK™ Module | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 110 A | 173 A | 2.5 V | 100 mA | 2400A @ 50Hz | 150 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
VWO85-14IO1MODULE AC CTLR 3PH 1400V V2-PACK |
8,286 | 0.00 |
|
Datasheet |
- | Module | Box | Obsolete | 3-Phase Controller - All SCRs | 6 SCRs | 1.4 kV | 27 A | 59 A | 1.5 V | 100 mA | 520A, 560A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCD132-14IO1MOD THYRISTOR/DIODE 1400V Y4-M6 |
9,216 | 0.00 |
|
Datasheet |
- | Y4 | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.4 kV | 130 A | 300 A | 2.5 V | 150 mA | 4750A, 5080A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
T620043004DNSCR PHASE CTRL MOD 400V 300A |
3,222 | 0.00 |
|
Datasheet |
- | TO-200AB, A-PUK | Bulk | Discontinued at Digi-Key | Single | 1 SCR | 400 V | 300 A | 470 A | 3 V | 150 mA | 5000A, 5500A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount, 8" Wire Lead |
