SCRs - Modules
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MCD431-22IO2MCD 431 - 22 IO2 |
3,206 | 0.00 |
|
- |
- | Module | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 2.2 kV | 429 A | 1020 A | 2.5 V | 250 mA | 12000A @ 50Hz | 300 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
PD250GB80THYRISTOR MODULE 800V 250A |
2,637 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 800 V | 250 A | 390 A | 3 V | 100 mA | 5000A, 5500A | 50 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
|
MCC500-16IO1THYRISTOR DIODE MOD 1600V M##500 |
9,570 | 0.00 |
|
Datasheet |
- | WC-500 | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 545 A | 1294 A | 3 V | 300 mA | 16500A @ 50Hz | 1 A | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MDNA600P2200PT-PCMDNA600P2200PTSF-PC |
5,940 | 0.00 |
|
- |
- | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
VS-VSKT230-20PBFMODULE DIODE SCR 230A MAGN-A-PAK |
6,991 | 0.00 |
|
Datasheet |
- | MAGN-A-PAK | Bulk | Last Time Buy | Series Connection - All SCRs | 2 SCRs | 2 kV | 230 A | 510 A | 3 V | 200 mA | 7500A, 7850A | 500 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
|
PK250HB160THYRISTOR MODULE 1600V 250A |
7,136 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 250 A | 390 A | 3 V | 100 mA | 5000A, 5500A | 50 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
|
T9G0201003DHSCR PHASE CTRL MOD 2000V 1000A |
4,707 | 0.00 |
|
Datasheet |
- | TO-200 Variation | Bulk | Discontinued at Digi-Key | Single | 1 SCR | 2 kV | 1000 A | 1590 A | 3 V | 200 mA | 15500A, 17000A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
F18107HD1000MODULE SCR/DIODE 105A 380VAC |
8,125 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Not For New Designs | Series Connection - SCR/Diode | 2 SCRs | 1 kV | - | - | 3 V | 150 mA | 2250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
VS-VSKH250-16PBFMODULE DIODE 250A MAGN-A-PAK |
8,508 | 0.00 |
|
Datasheet |
- | MAGN-A-PAK (3) | Bulk | Last Time Buy | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 400 V | 250 A | 555 A | 3 V | 200 mA | 8500A, 8900A | 500 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
|
VS-VSKL250-16PBFMODULE DIODE 250A MAGN-A-PAK |
8,164 | 0.00 |
|
Datasheet |
- | MAGN-A-PAK | Bulk | Last Time Buy | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 400 V | 250 A | 555 A | 3 V | 200 mA | 8500A, 8900A | 500 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount |
|
|
F1842SDK1200MODULE SCR/DIODE 40A 480VAC |
5,298 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.2 kV | - | - | 3 V | 150 mA | 1000A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
F18107SD400MODULE SCR/DIODE 105A 120VAC |
7,998 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 400 V | - | - | 3 V | 150 mA | 2250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
F18107SDK600MODULE SCR/DIODE 105A 240VAC |
6,094 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 600 V | - | - | 3 V | 150 mA | 2250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
MCC501-18IO2SCR THY PHASE LEG 1800V WC-501 |
4,478 | 0.00 |
|
Datasheet |
- | WC-501 | Box | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.8 kV | - | - | - | - | 14500A @ 50Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCD501-16IO2MOD THYRISTOR DUAL 1.6KV |
2,109 | 0.00 |
|
Datasheet |
- | Module | Box | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | - | - | - | - | 14500A @ 50Hz | - | 125°C (TJ) | - | - | Chassis Mount |
|
|
F1857SD1400MODULE SCR/DIODE 55A 530VAC |
3,113 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.4 kV | - | - | 3 V | 150 mA | 1500A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
F1892HD1000MODULE SCR/DIODE 90A 380VAC |
7,236 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1 kV | - | - | 3 V | 150 mA | 1950A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
T720N12TOFXPSA1SCR MODULE 1800V 1500A DO200AB |
8,840 | 0.00 |
|
Datasheet |
- | DO-200AB, B-PUK | Tray | Obsolete | Single | 1 SCR | 1.8 kV | 720 A | 1500 A | 1.5 V | 250 mA | 14500A @ 50Hz | 300 mA | -40°C ~ 125°C | - | - | Clamp On |
|
|
F1842SD1600MODULE SCR/DIODE 40A 600VAC |
4,496 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.6 kV | - | - | 3 V | 150 mA | 1000A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
F1842SDK1600MODULE SCR/DIODE 40A 600VAC |
9,957 | 0.00 |
|
Datasheet |
F18 | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.6 kV | - | - | 3 V | 150 mA | 1000A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
