| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
APTGT150DH60TGIGBT MODULE 600V 225A 480W SP4 |
5,701 | 0.00 |
|
- |
- | SP4 | Bulk | Active | Trench Field Stop | Asymmetrical Bridge | 600 V | 225 A | 480 W | 1.9V @ 15V, 150A | 250 µA | 9.2 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | SP4 |
|
MG1275W-XBN2MMIGBT MOD 1200V 105A 348W |
5,053 | 0.00 |
|
- |
- | Module | Bulk | Obsolete | - | Three Phase Inverter with Brake | 1200 V | 105 A | 348 W | 1.7V @ 15V, 75A | 1 mA | 5.3 nF @ 25 V | Three Phase Bridge Rectifier | Yes | -40°C ~ 125°C (TJ) | Chassis Mount | Module |
|
CM300DX-24SIGBT MOD 1200V 300A 2270W |
6,166 | 0.00 |
|
- |
IGBTMOD™ | Module | Bulk | Discontinued at Digi-Key | - | Half Bridge | 1200 V | 300 A | 2270 W | 2.15V @ 15V, 300A | 1 mA | 30 nF @ 10 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | Module |
|
APTCV60HM45BT3GIGBT MODULE 600V 50A 250W SP3 |
5,669 | 0.00 |
|
- |
- | SP3 | Bulk | Active | Trench Field Stop | Boost Chopper, Full Bridge | 600 V | 50 A | 250 W | 1.9V @ 15V, 50A | 250 µA | 3.15 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount | SP3 |
|
|
APTGTQ100H65T3GIGBT MODULE 650V 100A 250W SP3F |
7,849 | 0.00 |
|
- |
- | Module | Bulk | Active | - | Full Bridge | 650 V | 100 A | 250 W | 2.2V @ 15V, 100A | 100 µA | 6 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | SP3F |
|
|
APTGTQ200A65T3GIGBT MODULE 650V 200A 483W SP3F |
4,240 | 0.00 |
|
- |
- | Module | Bulk | Active | - | Half Bridge | 650 V | 200 A | 483 W | 2.2V @ 15V, 200A | 200 µA | 12 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | SP3F |
|
|
APTGLQ100A120TGIGBT MODULE 1200V 170A 520W SP4 |
3,650 | 0.00 |
|
- |
- | Module | Bulk | Active | Trench Field Stop | Half Bridge | 1200 V | 170 A | 520 W | 2.42V @ 15V, 100A | 50 µA | 6.15 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | SP4 |
|
|
APTGT100A120T3AGIGBT MODULE 1200V 140A 595W SP3 |
3,533 | 0.00 |
|
- |
- | SP3 | Bulk | Active | Trench Field Stop | Half Bridge | 1200 V | 140 A | 595 W | 2.1V @ 15V, 100A | 250 µA | 7.2 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Through Hole | SP3 |
|
|
FS200R07N3E4RPBPSA1LOW POWER ECONO |
4,717 | 0.00 |
|
- |
- | - | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
APTCV60HM45RCT3GIGBT MODULE 600V 50A 250W SP3 |
2,984 | 0.00 |
|
- |
- | SP3 | Bulk | Active | Trench Field Stop | Full Bridge Inverter | 600 V | 50 A | 250 W | 1.9V @ 15V, 50A | 250 µA | 3.15 nF @ 25 V | Single Phase Bridge Rectifier | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | SP3 |
|
MG12225WB-BN2MMIGBT MODULE 1200V 325A 1050W WB |
6,772 | 0.00 |
|
- |
- | Module | Bulk | Obsolete | Trench Field Stop | Half Bridge | 1200 V | 325 A | 1050 W | 1.7V @ 15V, 225A (Typ) | 1 mA | 16 nF @ 25 V | Standard | Yes | -40°C ~ 125°C (TJ) | Chassis Mount | WB |
|
|
VS-GT400LH060NMODULES IGBT - DIAP IGBT |
6,907 | 0.00 |
|
- |
FRED Pt® | Module | Bulk | Active | Trench Field Stop | Single Chopper | 600 V | 492 A | 1363 W | 2V @ 15V, 400A | 20 µA | - | Standard | No | -40°C ~ 175°C (TJ) | Chassis Mount | Double INT-A-PAK |
|
|
NXH800A100L4Q2F2P1GMASS MARKET GEN3 Q2PACK POSITIVE |
4,219 | 0.00 |
|
- |
- | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1000 V | 309 A | 714 W | 2.3V @ 15V, 400A | 20 µA | 49700 pF @ 20 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | 51-PIM/Q2PACK (93x47) |
|
|
FD300R17KE4HPSA1MEDIUM POWER 62MM |
6,375 | 0.00 |
|
- |
- | - | Tray | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
FMG2G400LS60IGBT MOD 600V 400A 1136W 7PMIA |
9,219 | 0.00 |
|
- |
- | 7PM-IA | - | Obsolete | - | Half Bridge | 600 V | 400 A | 1136 W | 1.8V @ 15V, 400A | 250 µA | - | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | 7PM-IA |
|
|
DDB6U84N16RRBPSA1LOW POWER ECONO AG-ECONO2A-211 |
8,969 | 0.00 |
|
- |
- | Module | Tray | Obsolete | - | Single Chopper | 1200 V | 50 A | 350 W | 3.2V @ 20V, 50A | 1 mA | 3.3 nF @ 25 V | Standard | No | 150°C (TJ) | Chassis Mount | AG-ECONO2A |
|
|
MIXG120W1200PTEHIGBT MODULE - SIXPACK E3-PACK-PF |
7,188 | 0.00 |
|
- |
- | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MIXG120W1200TEHIGBT MODULE - SIXPACK E3-PACK-PF |
7,035 | 0.00 |
|
- |
- | E3 | Box | Active | PT | Three Phase Inverter | 1200 V | 186 A | 625 W | 2V @ 15V, 100A | 2 mA | - | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | E3 |
|
|
MG17150D-BN4MMIGBT MODULE 1700V 250A 890W D3 |
3,610 | 0.00 |
|
- |
- | D-3 Module | Bulk | Obsolete | Trench Field Stop | Half Bridge | 1700 V | 250 A | 890 W | 2.45V @ 15V, 150A | 3 mA | 13.6 nF @ 25 V | Standard | No | -40°C ~ 125°C (TJ) | Chassis Mount | D3 |
|
|
MID300-12A4IGBT MOD 1200V 330A 1380W Y3DCB |
2,947 | 0.00 |
|
- |
- | Y3-DCB | Box | Obsolete | NPT | Single | 1200 V | 330 A | 1380 W | 2.7V @ 15V, 200A | 13 mA | 13 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount | Y3-DCB |
