SCRs - Modules
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B554-2TMOD DIODE SCR 25A 480VAC .250"QC |
6,879 | 0.00 |
|
Datasheet |
B-2T | Module | Bulk | Obsolete | 1-Phase Controller - All SCRs | 2 SCRs | 1.2 kV | - | - | 2.5 V | 60 mA | 250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
CD631615BSCR MOD DUAL 1600V 150A |
5,315 | 0.00 |
|
Datasheet |
- | POW-R-BLOK™ Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 160 A | 235 A | 2 V | 150 mA | 5000A, 5250A | 150 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
MCMA160P1800YA-MISCR MODULE 1.8KV 160A MODULE |
3,939 | 0.00 |
|
Datasheet |
- | Module | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.8 kV | 160 A | 250 A | 2.5 V | 150 mA | 4750A, 5130A | 200 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
|
MCMA200P1600SASCR MODULE 1.6KV 200A MODULE |
9,751 | 0.00 |
|
- |
- | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 200 A | 314 A | 2.5 V | 150 mA | 6000A, 6480A | 200 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
|
T620143004DNSCR PHASE CTRL MOD 1400V 300A |
2,939 | 0.00 |
|
Datasheet |
- | TO-200AB, A-PUK | Bulk | Discontinued at Digi-Key | Single | 1 SCR | 1.4 kV | 300 A | 470 A | 3 V | 150 mA | 5000A, 5500A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount, 8" Wire Lead |
|
VS-VSKT162/14PBFMOD PH CTRL 1400V 160A INT-A-PAK |
7,440 | 0.00 |
|
Datasheet |
- | INT-A-PAK (3) | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.4 kV | 160 A | 355 A | 2.5 V | 150 mA | 4870A, 5100A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
VS-VSKT142/16PBFMODULE THYRISTOR 145A INT-A-PAK |
2,385 | 0.00 |
|
Datasheet |
- | INT-A-Pak | Bulk | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 140 A | 310 A | 2.5 V | 150 mA | 4500A, 4712A | 200 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
VVZB135-16NO1RECT BRIDGE 3PH 135A 1600V E2 |
3,605 | 0.00 |
|
- |
- | E2 | Box | Obsolete | Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode | 3 SCRs, 3 Diodes | 1.6 kV | 135 A | - | 1.5 V | 78 mA | - | 100 mA | -40°C ~ 150°C (TJ) | - | - | Chassis Mount |
|
|
MCMA200P1800YA-MISCR MODULE 1.8KV 200A MODULE |
8,872 | 0.00 |
|
Datasheet |
- | Module | Box | Active | Series Connection - All SCRs | 2 SCRs | 1.8 kV | 200 A | 315 A | 2.5 V | 150 mA | 6000A, 6480A | 200 mA | -40°C ~ 140°C (TJ) | - | - | Chassis Mount |
|
|
VWO80-12IO7MODULE AC CTLR 3PH 1200V PWS-F |
7,546 | 0.00 |
|
Datasheet |
- | Module | Box | Obsolete | 3-Phase Controller - All SCRs | 6 SCRs | 1.2 kV | 37 A | 59 A | 1 V | 100 mA | 1000A, 1100A | 150 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
VWO95-12IO7MODULE AC CTLR 3PH 1200V PWS-F |
9,113 | 0.00 |
|
Datasheet |
- | Module | Box | Obsolete | 3-Phase Controller - All SCRs | 6 SCRs | 1.2 kV | 44 A | 69 A | 1 V | 100 mA | 1150A, 1230A | 150 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
PD200FG160THYRISTOR MODULE 800V 200A |
4,928 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | 200 A | 314 A | 3 V | 100 mA | 6000A, 6500A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
|
PD200FG80THYRISTOR MODULE 1600V 200A |
3,299 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 800 V | 200 A | 314 A | 3 V | 100 mA | 6000A, 6500A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
SCE160DA80THYRISTOR MODULE 800V 160A |
7,714 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 800 V | 160 A | 251 A | 3 V | 100 mA | 5400A, 5900A | 140 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
|
SCE160DA160THYRISTOR MODULE 1600V 160A |
2,674 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 1.6 kV | 160 A | 251 A | 3 V | 100 mA | 5400A, 5900A | 140 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
|
T552MODULE POWER |
4,227 | 0.00 |
|
Datasheet |
- | Module | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
B611F-2TMOD DIODE SCR 42.5A 120V .250"QC |
3,116 | 0.00 |
|
Datasheet |
B-2T | Module | Bulk | Active | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 400 V | - | - | 3 V | 80 mA | 600A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
B622F-2TMOD DIODE SCR 42.5A 240V .250"QC |
8,896 | 0.00 |
|
Datasheet |
B-2T | Module | Bulk | Obsolete | Bridge, Single Phase - SCRs/Diodes (Layout 2) | 2 SCRs, 2 Diodes | 600 V | - | - | 3 V | 80 mA | 600A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
PGH50N16THYRISTOR MODULE 3PHASE LEG T+D |
9,134 | 0.00 |
|
Datasheet |
- | Module | Bulk | Active | Bridge, 3-Phase - SCRs/Diodes | 1 SCR, 6 Diodes | 1.6 kV | 50 A | - | 2.5 V | 100 mA | 1200A @ 50Hz | 80 mA | -40°C ~ 150°C (TJ) | - | - | Chassis Mount |
|
|
PK160FG80THYRISTOR MODULE 800V 160A |
8,984 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - All SCRs | 2 SCRs | 800 V | 160 A | 251 A | 3 V | 100 mA | 5000A, 5400A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
