SCRs - Modules
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Structure | Number of SCRs, Diodes | Voltage - Off State | Current - On State (It (AV)) (Max) | Current - On State (It (RMS)) (Max) | Voltage - Gate Trigger (Vgt) (Max) | Current - Gate Trigger (Igt) (Max) | Current - Non Rep. Surge 50, 60Hz (Itsm) | Current - Hold (Ih) (Max) | Operating Temperature | Grade | Qualification | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SCE160CA200THYRISTOR MODULE 2000V 160A |
5,734 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 2 kV | 160 A | 251 A | 3 V | 100 mA | 4100A, 4500A | 180 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount | |
|
T582MODULE POWER |
6,755 | 0.00 |
|
Datasheet |
- | Module | Bulk | Not For New Designs | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
TDB6HK180N16RRB48BPSA2LOW POWER ECONO AG-ECONO2B-411 |
6,574 | 0.00 |
|
- |
EconoPACK™ 2 | Module | Tray | Active | Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode | 3 SCRs, 3 Diodes | 1.6 kV | - | - | 2 V | 100 mA | 1600A @ 50Hz | 220 mA | 175°C (TJ) | - | - | Chassis Mount |
|
|
VS-ST380C06C0LTHYRISTOR 600V 960A PUCK |
2,608 | 0.00 |
|
Datasheet |
- | TO-200AB, E-PUK | Bulk | Last Time Buy | Single | 1 SCR | 600 V | 960 A | 1900 A | 3 V | 200 mA | 15000A, 15700A | 600 mA | -40°C ~ 125°C (TJ) | - | - | Clamp On |
|
|
VVZB170-16IOXTDIODE BRIDGE 1600V 180A |
7,315 | 0.00 |
|
Datasheet |
- | E2 | Box | Active | Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode | 3 SCRs, 3 Diodes | 1.6 kV | - | - | 1.5 V | 95 mA | 1100A, 1190A | 200 mA | -40°C ~ 150°C (TJ) | - | - | Chassis Mount |
|
|
VVZB170-16IOXT-PFPBIPOLAR MODULE-THYRISTOR/DIODE E |
2,751 | 0.00 |
|
- |
- | E2 | Bulk | Active | Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode | 3 SCRs, 3 Diodes | 1.6 kV | 48 A | 200 A | 1.5 V | 95 mA | 1100A, 1190A | 200 mA | -40°C ~ 150°C (TJ) | - | - | Chassis Mount |
|
B544-2TMOD DIODE SCR 25A 480VAC .250"QC |
5,813 | 0.00 |
|
Datasheet |
B-2T | Module | Bulk | Obsolete | Bridge, Single Phase - All SCRs | 4 SCRs | 1.2 kV | - | - | 2.5 V | 60 mA | 250A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
SCA200DA80THYRISTOR MODULE 800V 240A |
2,811 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - All SCRs | 2 SCRs | 800 V | 200 A | 314 A | 3 V | 100 mA | 6000A, 6500A | 140 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
|
SCA200DA160THYRISTOR MODULE 1600V 200A |
2,615 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - All SCRs | 2 SCRs | 1.6 kV | 200 A | 314 A | 3 V | 100 mA | 6000A, 6500A | 140 mA | -40°C ~ 125°C (TJ) | - | - | Chassis Mount | |
|
|
TDB6HK180N22RRPB11BPSA1LOW POWER ECONO AG-ECONO2B-411 |
2,646 | 0.00 |
|
Datasheet |
ECOPACK®2 | Module | Tray | Active | Bridge, 3-Phase - SCRs/Diodes - IGBT with Diode | 3 SCRs, 3 Diodes | 2.2 kV | - | - | 1.5 V | 70 mA | - | - | -40°C ~ 150°C (TJ) | - | - | Chassis Mount |
|
|
B613F-2TMOD DIODE SCR 42.5A 280V .250"QC |
3,384 | 0.00 |
|
Datasheet |
B-2T | Module | Bulk | Active | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 800 V | - | - | 3 V | 80 mA | 600A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
MCK200-18IO1MOD THYRISTOR DUAL 18KV |
6,981 | 0.00 |
|
Datasheet |
- | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
DFA150BA160DIODE MODULE 1600V 150A |
6,755 | 0.00 |
|
Datasheet |
- | Module | Active | Bridge, 3-Phase - SCRs/Diodes | 1 SCR, 6 Diodes | 1.6 kV | 150 A | - | 3 V | 70 mA | 1460A, 1600A | 100 mA | -40°C ~ 150°C (TJ) | - | - | Chassis Mount | |
|
|
TT122N18KOFHPSA1SCR MODULE 1.8KV 160A MODULE |
2,833 | 0.00 |
|
Datasheet |
- | Module | Bulk | Obsolete | Series Connection - All SCRs | 2 SCRs | 1.8 kV | 104 A | 160 A | 1.4 V | 120 mA | 1050A @ 50Hz | 200 mA | -40°C ~ 140°C | - | - | Chassis Mount |
|
|
B614F-2MOD DIODE SCR 42.5A 380V ISO QC |
7,901 | 0.00 |
|
Datasheet |
B-2 | Module with Isolation Barriers | Bulk | Obsolete | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 1.2 kV | - | - | 3 V | 80 mA | 600A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
|
SCE200CA200THYRISTOR MODULE 2000V 200A |
5,005 | 0.00 |
|
Datasheet |
- | Module | Active | Series Connection - SCR/Diode | 1 SCR, 1 Diode | 2 kV | 200 A | 314 A | 3 V | 100 mA | 5000A, 5500A | 180 mA | -40°C ~ 130°C (TJ) | - | - | Chassis Mount | |
|
T620163004DNSCR PHASE CTRL MOD 1600V 300A |
7,323 | 0.00 |
|
Datasheet |
- | TO-200AB, A-PUK | Bulk | Active | Single | 1 SCR | 1.6 kV | 300 A | 470 A | 3 V | 150 mA | 5000A, 5500A | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount, 8" Wire Lead |
|
|
MDMA210UB1600P-PCMDMA210UB1600PTED-PC |
3,602 | 0.00 |
|
- |
- | - | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
B612F-2T-YECMOD DIODE SCR 42.5A 240V .250"QC |
2,039 | 0.00 |
|
Datasheet |
B-2T | Module | Bulk | Obsolete | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 600 V | - | - | 3 V | 80 mA | 600A @ 60Hz | - | -40°C ~ 125°C (TJ) | - | - | Chassis Mount |
|
L412FMODULE BRIDGE RECT SLG PHASE 12A |
5,390 | 0.00 |
|
Datasheet |
L | Module | Bulk | Not For New Designs | Bridge, Single Phase - SCRs/Diodes (Layout 1) | 2 SCRs, 2 Diodes | 600 V | 100 A | 22 A | 2.5 V | 100 mA | - | 100 mA | -40°C ~ 125°C (TJ) | - | - | - |
