ams-OSRAM USA INC. AS5270A-HMFM
- Part No.:
- AS5270A-HMFM
- Manufacturer:
- ams-OSRAM USA INC.
- Category:
- Angle, Linear Position Measuring
- Package:
- 16-VQFN Exposed Pad
- Datasheet:
-
AS5270A-HMFM.pdf
- Description:
- SENSOR ANGLE 90DEG SURFACE MOUNT
- Quantity:
- Payment:

- Shipping:

Inventory:1,066
Please send an inquiry. Send us your inquiry, and we will respond immediately.
AS5270A-HMFM Specifications
- Product attributes
- Attribute value
- Manufacturer:
- ams-OSRAM USA INC.
- Package/Case:
- 16-VQFN Exposed Pad
- Series:
- -
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Programmable:
- -
- For Measuring:
- Angle
- Technology:
- Hall Effect
- Rotation Angle - Electrical, Mechanical:
- 90° (±45°)
- Linear Range:
- -
- Output:
- Analog Voltage
- Output Signal:
- Clockwise Increase
- Actuator Type:
- External Magnet, Not Included
- Linearity:
- -
- Resistance:
- -
- Resistance Tolerance:
- -
- Voltage - Supply:
- 4.5V ~ 5.5V
- Mounting Type:
- Surface Mount
- Termination Style:
- SMD (SMT) Tab
- Operating Temperature:
- -40°C ~ 150°C
- Grade:
- -
- Qualification:
- -
- Supplier Device Package:
- 16-MLF (6x6)
