International Rectifier AUIPS1011R
- Part No.:
- AUIPS1011R
- Manufacturer:
- International Rectifier
- Package:
- TO-252-3, DPAK (2 Leads + Tab), SC-63
- Datasheet:
-
AUIPS1011R.pdf
- Description:
- AUIPS1011 - HITFET, AUTOMOTIVE S
- Quantity:
- Payment:

- Shipping:

Inventory:415
Please send an inquiry. Send us your inquiry, and we will respond immediately.
Product details
Overview
AUIPS1011R from International Rectifier is an Automotive-grade intelligent power low-side switch with integrated MOSFET driver and protection functions supplied in the TO-252-3, DPAK (2 Leads + Tab), SC-63 package. Unlike a bare MOSFET, it combines the power switch with fault protection functions such as over-current shutdown, over-temperature shutdown, ESD protection, and active clamp behavior for inductive-load turn-off.
For engineers reviewing the AUIPS1011R datasheet, AUIPS1011R pinout, AUIPS1011R application, or AUIPS1011R equivalent, this device is commonly used in automotive low-side load switching, relay, solenoid & actuator control, protected output channels, and legacy board replacement designs. The device is selected for low-side load paths where the load is tied to the positive supply and AUIPS1011R controls the ground return. RDS(on) is 13 mΩ maximum, defining conduction loss and voltage drop under load current.
Technical Context
In circuit use, AUIPS1011R sits between the load and system ground. The input pin receives a logic-level command while the drain carries load current, so the drain copper area, source return, and input routing should be designed separately rather than treated as a simple signal device.
The protection behavior is a main selection point. During overload or short-circuit conditions, the internal switch shuts down instead of relying only on an external fuse; during inductive turn-off, the active clamp path handles stored magnetic energy within the rated clamp and thermal limits.
For production design, AUIPS1011R should be checked for RDS(on), current shutdown threshold, clamp voltage, thermal shutdown behavior, junction-temperature rise, and reset behavior after a latched fault. These details determine whether it can replace a discrete MOSFET plus external protection network.
Key Specifications
| Parameter | Value and Actual Design Meaning |
|---|---|
| Device Type | Automotive-grade intelligent power low-side switch with integrated MOSFET driver and protection functions. |
| Package | TO-252-3, DPAK (2 Leads + Tab), SC-63; DPAK / TO-252 surface-mount package for medium-current switching with PCB copper thermal spreading. |
| Base Device Family | AUIPS1011 fully protected / intelligent low-side switch family. |
| Output Configuration | Single low-side N-channel output used to switch the ground-side return of an external load. |
| On-State Resistance | 13 mΩ maximum RDS(on), defining conduction loss and voltage drop under load current. |
| Active Clamp Voltage | 39 V, supporting inductive-load demagnetization during switch turn-off. |
| Shutdown Current | 85 A typical, used by the internal protection circuit to turn off the MOSFET under overload conditions. |
| Thermal Shutdown | Turns off the power MOSFET when junction temperature exceeds the shutdown threshold, typically around 165°C in this product family. |
| Input Control | Low-current logic-level input suitable for MCU, logic, or driver control in load-switching circuits. |
| Protection Functions | Over-current shutdown, over-temperature shutdown, ESD protection, and drain-to-source active clamp. |
| Typical Switching Role | Protected switching of relays, lamps, solenoids, actuators, and other low-side loads. |
| Design Source | International Rectifier AUIPS1011 technical documentation family data |
Pinout & Package
The AUIPS1011R pinout must be reviewed from the exact package drawing because terminal function, thermal path, and mechanical footprint are linked in this product family. TO-252-3, DPAK (2 Leads + Tab), SC-63 package information and Bulk packaging for this line.
For PCB design, use the package drawing and confirm copper area, soldering method, creepage or clearance where applicable, and the final orderable suffix before layout or replacement approval. DPAK / TO-252 surface-mount package for medium-current switching with PCB copper thermal spreading.
| Pin / Function | PCB Design and Circuit Role |
|---|---|
| IN | logic-control input for turning the protected low-side switch on and off; a series input resistor may be used where the technical documentation diagnostic method requires it. |
| Drain / Tab | power terminal connected to the low side of the external load; the tab also acts as the major heat-spreading path in DPAK/D²Pak versions. |
| Source | power-ground return for switched load current; route with low impedance and keep noisy load current away from logic ground references. |
| Load Connection | external load is normally placed between the positive supply and the drain terminal, while the device switches the low-side return path. |
Key Features
- Automotive-grade intelligent power low-side switch with integrated MOSFET driver and protection functions for protected low-side load control.
- Integrated MOSFET switching path reduces external protection circuitry.
- Over-current shutdown and thermal shutdown support fault-tolerant output-channel design.
- Active clamp behavior supports inductive-load turn-off within rated clamp and thermal limits.
- TO-252-3, DPAK (2 Leads + Tab), SC-63 package affects thermal spreading, footprint compatibility, and assembly process.
- Input-controlled operation supports MCU or logic-driven load switching.
Applications
| Automotive Low-Side Load Switching | Relay, Solenoid & Actuator Control |
|---|---|
|
Use Scenario: 12 V body-control outputs, auxiliary loads, lamps, small motors, and protected power-distribution channels. IC Role: AUIPS1011R switches the ground-side return path while adding built-in current and thermal protection. Use Value: Improves robustness compared with an unprotected discrete MOSFET output. |
Use Scenario: Inductive loads such as relays, solenoid valves, small actuators, and motor-control auxiliaries. IC Role: AUIPS1011R provides low-side switching and clamp behavior for turn-off energy management. Use Value: Reduces external suppression and protection circuitry when technical documentation energy limits are respected. |
| Protected Output Channels | Legacy Board Replacement |
|
Use Scenario: ECU outputs, industrial controller outputs, and serviceable low-side driver channels. IC Role: AUIPS1011R combines switching, fault shutdown, and diagnostic current behavior in one device. Use Value: Simplifies protected output-channel design and helps reduce field-failure risk. |
Use Scenario: Boards already using International Rectifier IPS/AUIPS low-side switch footprints. IC Role: AUIPS1011R supplies a package- and suffix-specific replacement reference. Use Value: Supports BOM continuity when package, orientation, and electrical protection behavior match. |
Equivalent & Alternatives
When evaluating AUIPS1011R equivalent devices, engineers should compare only specific orderable alternatives and should verify package footprint, pinout, electrical ratings, thermal data, qualification status, and suffix or packing requirements before substitution.
| Alternative Part | Technical Difference | Application Difference | Selection Advice |
|---|---|---|---|
| AUIPS1011 | Same base family or close suffix variant; electrical function may be similar, while package, reel orientation, lead finish, or orderable code can differ. | Used when the existing design needs the same functional device with a different supply or assembly code. | Compare AUIPS1011 against AUIPS1011R for package drawing, suffix meaning, tape orientation, and documentation revision. |
| IPS021 | Related International Rectifier / Infineon orderable device; electrical ratings, package, and protection behavior may differ. | Used as a possible functional alternative in redesigned or revalidated circuits. | Use only after comparing IPS021 and AUIPS1011R electrical ratings, package, pinout, and thermal behavior; do not assume drop-in compatibility. |
| IPS031 | Related International Rectifier / Infineon orderable device; electrical ratings, package, and protection behavior may differ. | Used as a possible functional alternative in redesigned or revalidated circuits. | Use only after comparing IPS031 and AUIPS1011R electrical ratings, package, pinout, and thermal behavior; do not assume drop-in compatibility. |
Compared with related alternatives, AUIPS1011R should remain the preferred sourcing reference when the existing BOM, PCB footprint, and qualification documentation require the exact International Rectifier orderable device.
Quality
AUIPS1011R should be sourced as original International Rectifier / Infineon inventory through traceable and controlled supply channels. Quality verification may include package inspection, top-mark validation, label and lot review, solderability inspection, moisture-sensitivity handling review, and electrical screening according to the target production requirement.
Because AUIPS1011R is used in protected low-side switching circuits, final validation should include the actual PCB footprint, thermal path, electrical stress, operating temperature, and fault-condition behavior. Traceable sourcing helps reduce counterfeit risk and supports repeatable performance in production, repair, and maintenance programs.
Availability
AUIPS1011R available at Aetrix Electronics and suitable for protected low-side switching circuits requiring stable component supply, package matching, and controlled replacement planning.
Supply support may include scheduled delivery planning, volume procurement support, BOM continuity assistance, traceable sourcing management, and long-term availability support for OEM manufacturers, repair programs, and electronics production teams.
For production or repair deployment, confirming package type, orderable suffix, lifecycle status, environmental requirement, electrical rating, thermal condition, and sourcing continuity helps reduce procurement risk and improve manufacturing stability.
Manufacturer
International Rectifier was a semiconductor manufacturer known for power MOSFETs, IGBTs, gate drivers, power-management ICs, intelligent power switches, photovoltaic relays, and power modules. International Rectifier products became part of Infineon Technologies' power semiconductor portfolio after the acquisition of International Rectifier.
The AUIPS1011R ordering line should be reviewed with the relevant International Rectifier legacy technical documentation and Infineon supply-chain references where available. This is especially important for legacy MOSFETs, IRAM modules, PV relay products, and automotive AUIR power devices.
FAQ
What is AUIPS1011R used for?
AUIPS1011R is used in protected low-side switching circuits. The exact application depends on the technical documentation electrical ratings, package, pinout, and thermal capability.
Where can I find the AUIPS1011R technical documentation?
The AUIPS1011R technical documentation should be obtained from International Rectifier / Infineon documentation or an authorized technical documentation source. It should be used to confirm ratings, package information, pinout, thermal data, and test conditions.
What should be considered in AUIPS1011R pinout design?
Pinout design should confirm the package drawing, terminal functions, thermal path, high-current routing or isolation spacing, and whether the orderable suffix changes package or packing details.
Can AUIPS1011R be used as a direct replacement?
AUIPS1011R can be used as a direct replacement only when the package footprint, pinout, electrical ratings, thermal behavior, and qualification status match the original design.
What are common AUIPS1011R equivalent solutions?
Equivalent solutions should be limited to specific orderable devices with verified technical documents. Suffix variants may differ in package, reel orientation, lead finish, qualification, or manufacturing status.
AUIPS1011R Specifications
- Product attributes
- Attribute value
- Manufacturer:
- International Rectifier
- Package/Case:
- TO-252-3, DPAK (2 Leads + Tab), SC-63
- Series:
- -
- Packaging:
- Bulk
- Product Status:
- Obsolete
- Switch Type:
- General Purpose
- Number of Outputs:
- 1
- Ratio - Input:Output:
- 1:1
- Output Configuration:
- Low Side
- Output Type:
- N-Channel
- Interface:
- On/Off
- Voltage - Load:
- 36V (Max)
- Voltage - Supply (Vcc/Vdd):
- Not Required
- Current - Output (Max):
- 6A
- Rds On (Typ):
- 10mOhm
- Input Type:
- Non-Inverting
- Features:
- -
- Fault Protection:
- Current Limiting (Fixed), Over Temperature
- Operating Temperature:
- -40°C ~ 150°C (TJ)
- Grade:
- Automotive
- Qualification:
- AEC-Q100
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- DPAK
