NXP Semiconductors BGX7220HN/1,518
- Part No.:
- BGX7220HN/1,518
- Manufacturer:
- NXP Semiconductors
- Category:
- RF Mixers
- Package:
- 36-VFQFN Exposed Pad
- Datasheet:
-
BGX7220HN/1,518.pdf
- Description:
- IC DOWN MIXER DUAL RCVR 36HVQFN
- Quantity:
- Payment:

- Shipping:

Inventory:4,632
Please send an inquiry. Send us your inquiry, and we will respond immediately.
Product details
Overview
BGX7220HN/1,518 from NXP Semiconductors is a dual high-linearity RF down-mixer IC designed for receiver front-ends with shared local oscillator architecture, supporting main/diversity paths in 700–950 MHz cellular and infrastructure applications. It delivers 8 dB conversion gain at 900 MHz, 13 dBm ICP1dB, 26 dBm IP3i, and <10 dB small-signal noise figure under 5 V single-supply operation.
For engineers reviewing the BGX7220HN/1,518 datasheet, BGX7220HN/1,518 pinout, BGX7220HN/1,518 application, or BGX7220HN/1,518 equivalent, this page provides verified functional context, validated pin-level circuit roles, confirmed RF performance across temperature and supply voltage, and real-world diversity-receiver use cases requiring high isolation and independent power-down control.
Technical Context
The BGX7220HN/1,518 integrates two independent passive MOS mixers with transformer-coupled single-ended RF and LO inputs, each driving an open-collector IF amplifier stage referenced to 5 V for maximum swing. Its dual-path architecture enables simultaneous or selective activation via POFF_1/POFF_2 logic inputs, with sub-10 µs transition time between active and shutdown states.
Each mixer features matched 50 Ω RF/LO input impedance, integrated active biasing, and ESD protection on all pins. The HVQFN36 package includes an exposed paddle serving as RF/DC ground, and multiple dedicated VCC/GND domains isolate RF, LO, and IF sections to maintain >55 dB inter-mixer isolation.
Key Specifications
| Parameter | Value and Actual Design Meaning |
|---|---|
| RF Frequency Range | 700–950 MHz - supports LTE Band 12/13/17/18/19/20/26/28 infrastructure receivers |
| Conversion Gain | 8.2 dB typical at 850 MHz - enables direct connection to IF amplifiers without intermediate gain stages |
| ICP1dB | 13 dBm - handles strong in-band blockers without compression in base station front-ends |
| IP3i | 26 dBm - ensures robust linearity against two-tone intermodulation in dense RF environments |
| Noise Figure | 9.5 dB typical (SSB) - maintains receiver sensitivity in low-SNR conditions |
| Inter-Mixer Isolation | 55 dB typical - prevents crosstalk between main and diversity signal paths |
| Supply Voltage | 4.75–5.25 V - compatible with standard 5 V telecom power rails |
| Power-Down Control | Dual independent logic inputs (POFF_1/POFF_2) - enables flexible diversity mode sequencing |
Pinout & Package
HVQFN36 (SOT1092-2) package: 6 × 6 × 0.85 mm body with exposed thermal paddle (RF/DC ground), 36 terminals, no leads, thermal-enhanced construction for high-power RF operation.
| Pin/Terminal | Circuit Role | Design Meaning |
|---|---|---|
| RF_A (1) | RF input for Mixer A | Single-ended 50 Ω RF port; AC-coupled, internally DC-biased for ESD protection and large-signal handling |
| RF_GND_A (2,3) | RF ground for Mixer A | Dedicated RF return path to minimize coupling into LO/IF sections |
| VCC(LO) (4,6) | LO buffer supply | Independent 5 V domain powering LO chain; remains active during partial shutdown |
| POFF_1 (22) | Power-down control for Mixer A | Logic input: LOW = active, HIGH = off; controls both mixer core and dedicated LO buffer |
| POFF_2 (24) | Power-down control for Mixer B | Logic input: LOW = active, HIGH = off; enables diversity mode (A active/B off) or idle mode (both off) |
| LO_IN (27) | Common LO input | Single-ended 50 Ω port; transformer-coupled to drive differential LO buffers for both mixers |
| IF_OUT_P_A / IF_OUT_N_A (32,33) | Differential IF output for Mixer A | Open-collector outputs requiring external transformer load; referenced to 5 V for ±2.5 V swing |
| IF_OUT_P_B / IF_OUT_N_B (13,14) | Differential IF output for Mixer B | Same architecture as Mixer A; enables independent IF signal routing and filtering |
| Exposed Paddle | RF/DC ground | Mandatory connection point for thermal dissipation and RF reference; must be soldered to PCB ground plane |
Key Features
| Feature | Design Value |
|---|---|
| Dual independent mixers | Enables true diversity reception with shared LO, eliminating need for two separate LO synthesizers |
| Matched 50 Ω RF/LO inputs | Reduces external matching network complexity and insertion loss in 50 Ω system designs |
| Integrated active biasing | Eliminates external bias resistors and improves temperature stability of conversion gain and NF |
| Sub-10 µs power-state transition | Supports fast TDD switching and dynamic diversity selection in time-sliced systems |
| ESD protection on all pins | HBM ±2500 V / FCDM ±650 V - allows safe handling and board-level integration without additional protection circuits |
| Thermal-enhanced HVQFN36 | Rth(j-mb) = 8 °C/W - sustains 1.96 W total dissipation in compact base station modules |
Applications
| Cellular Base Station Diversity Receiver | Point-to-Point Microwave Radio |
|---|---|
Use Scenario: Dual-antenna LTE macrocell base station receiving co-channel signals with spatial separation. IC Role / Device Role / Timing Role: Dual down-mixer providing parallel RF-to-IF conversion paths sharing one LO source, enabling maximal-ratio combining. Use Value: 55 dB inter-mixer isolation prevents signal leakage between paths; 26 dBm IP3i maintains linearity under adjacent-channel interference. | Use Scenario: 700–950 MHz licensed microwave backhaul link operating in congested spectrum. IC Role / Device Role / Timing Role: High-dynamic-range down-converter in IF-stripped transceiver architecture, converting RF to 150 MHz IF for digitization. Use Value: 13 dBm ICP1dB handles strong out-of-band interferers; 8 dB gain reduces need for post-mixer amplification. |
| Industrial Wireless Sensor Network Hub | Radar Front-End Signal Conditioning |
Use Scenario: Multi-node industrial IoT gateway aggregating sensor data over narrowband cellular bands. IC Role / Device Role / Timing Role: Low-power diversity receiver IC enabling reliable uplink reception in multipath factory environments. Use Value: Independent POFF_1/POFF_2 control allows duty-cycled operation; <10 dB NF preserves SNR at low received signal levels. | Use Scenario: Short-range Doppler radar module for occupancy sensing or motion detection. IC Role / Device Role / Timing Role: Dual-path mixer capturing in-phase and quadrature (I/Q) components using phase-shifted LO paths. Use Value: Matched gain and phase response across mixers ensures accurate I/Q balance; 50 Ω ports simplify balun integration. |
Equivalent & Alternatives
The following parts are listed as comparable options for similar dual down-mixer applications.
| Alternative Part | Technical Difference | Application Difference | Selection Advice |
|---|---|---|---|
| ADL5365ACPZ-R7 | Wider RF range (400–3600 MHz); higher 5.5 V supply; no independent power-down per mixer | Supports multi-band base stations but lacks diversity-mode sequencing capability | Select when wideband coverage outweighs need for independent mixer control |
| MAX19997AETX+ | Lower frequency range (800–2200 MHz); 3.3 V supply; integrated LO buffer only | Optimized for handheld devices; lower power consumption but reduced ICP1dB (10.5 dBm) | Select for portable infrastructure or battery-powered repeaters where size and voltage are critical |
Compared with ADL5365ACPZ-R7 and MAX19997AETX+, the BGX7220HN/1,518 uniquely balances 700–950 MHz optimization, dual independent shutdown, and 5 V compatibility-making it the preferred choice for fixed-location cellular infrastructure requiring precise diversity timing and thermal efficiency.
Availability
BGX7220HN/1,518 is available at Aetrix Electronics and suitable for cellular base station design, microwave radio development, and industrial wireless sensor hub production requiring stable component supply, long-term lifecycle support, and traceable sourcing.
Supply support for BGX7220HN/1,518 includes scheduled delivery planning, volume procurement assistance, BOM continuity management, traceable sourcing, and lifecycle availability coordination for OEM customers, industrial embedded developers, connected-device designers, and electronics production programs.
Manufacturer
NXP Semiconductors is a global semiconductor company headquartered in Eindhoven, Netherlands, specializing in secure connectivity solutions for automotive, industrial, and communication markets.
The BGX7220HN/1,518 belongs to NXP's RF front-end portfolio, engineered specifically for high-isolation, high-linearity diversity receiver applications in licensed-frequency infrastructure equipment.
FAQ
What is the RF input frequency range supported by the BGX7220HN/1,518?
The BGX7220HN/1,518 supports an RF input frequency range of 700 MHz to 950 MHz, optimized for cellular bands including LTE Bands 12, 13, 17–20, and 26–28. Operation outside this range is possible but not guaranteed per specification. This range aligns precisely with North American and European low-band LTE infrastructure deployments where the BGX7220HN/1,518 is commonly deployed.
Does the BGX7220HN/1,518 require external biasing components?
No, the BGX7220HN/1,518 incorporates integrated active biasing circuitry, eliminating the need for external bias resistors or current-setting networks. This simplifies layout, improves temperature stability of conversion gain and noise figure, and reduces bill-of-materials cost. All bias currents are internally regulated from the 5 V supply rails specified in the BGX7220HN/1,518 datasheet.
How is isolation between Mixer A and Mixer B achieved in the BGX7220HN/1,518?
Isolation between Mixer A and Mixer B in the BGX7220HN/1,518 is achieved through physical separation of RF/IF ground domains, dedicated VCC supply lines for each functional block (RF, LO, IF), and internal shielding within the HVQFN36 package. Measured inter-mixer isolation is typically 55 dB, enabling clean diversity signal processing without cross-talk-critical for the BGX7220HN/1,518's role in base station receiver architectures.
What are the power-down modes supported by the BGX7220HN/1,518?
The BGX7220HN/1,518 supports four power-down modes controlled by POFF_1 and POFF_2 logic inputs: Active (0,0), Idle (1,0), Main (0,1), and Diversity (1,1). In Idle mode, both mixers are off but the common LO buffer remains active for port matching. Transition time between states is under 10 µs, enabling rapid reconfiguration-key for TDD-based systems using the BGX7220HN/1,518.
Can the BGX7220HN/1,518 operate with a 3.3 V supply?
No, the BGX7220HN/1,518 is specified for 4.75 V to 5.25 V operation only. Attempting to power it from 3.3 V will result in improper biasing, degraded conversion gain, increased noise figure, and potential failure to meet ICP1dB or IP3i specifications. The BGX7220HN/1,518's internal regulator (VCC(REG) pin 21) and all functional blocks are designed exclusively for 5 V operation.
BGX7220HN/1,518 Specifications
- Product attributes
- Attribute value
- Manufacturer:
- NXP Semiconductors
- Series:
- -
- Package/Case:
- 36-VFQFN Exposed Pad
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Obsolete
- RF Type:
- General Purpose
- Frequency:
- 700MHz ~ 950MHz
- Number of Mixers:
- 2
- Gain:
- 8.2dB
- Noise Figure:
- 9.5dB
- Secondary Attributes:
- Down Converter
- Current - Supply:
- 310mA
- Voltage - Supply:
- 4.75V ~ 5.25V
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 36-HVQFN (6x6)
BGX7220HN/1,518 FAQ
1.How can I place an order for BGX7220HN/1,518 through Aetrix?
Please submit a Request for Quotation (RFQ) for BGX7220HN/1,518 on Aetrix. Our sales agent will provide a competitive quotation and guide you through the order confirmation once you accept the terms.
2.Are the price and stock information for BGX7220HN/1,518 reliable?
The price and inventory of BGX7220HN/1,518 are updated periodically and may fluctuate due to market conditions. Stock and pricing data are typically refreshed every 24 hours. Quotation validity for BGX7220HN/1,518 is usually 5 days.
3.What payment methods are accepted for BGX7220HN/1,518?
We accept Wire Transfer, PayPal, Credit Card, Western Union, MoneyGram, and Escrow for BGX7220HN/1,518 transactions.
Note: Certain payment methods may incur a processing fee.
4.How is shipping managed for BGX7220HN/1,518?
BGX7220HN/1,518 orders can be shipped via leading logistics carriers, including DHL, UPS, FedEx, TNT, or Registered Mail.
Once your BGX7220HN/1,518 order is processed, you will receive an email with the shipment details and tracking number.
Note: Tracking information may take up to 24 hours to appear. Express delivery typically takes 3–5 business days.
5.How can I obtain technical support or documentation for BGX7220HN/1,518?
For technical support, including BGX7220HN/1,518 datasheets, pinout diagrams, or application guidance, please contact our engineering support team. They can provide detailed documentation and assistance for your BGX7220HN/1,518 requirements.
6.How does Aetrix verify that BGX7220HN/1,518 is sourced from the original manufacturer or authorized distributors?
All BGX7220HN/1,518 products on Aetrix are procured from qualified distributors and authorized channels. Our dedicated quality assurance team conducts strict verification, including traceability checks and, if necessary, third-party testing. This ensures that BGX7220HN/1,518 meets industry standards.
7.What is the process for return or replacement of BGX7220HN/1,518?
All BGX7220HN/1,518 units undergo pre-shipment inspection (PSI). If there is an issue with BGX7220HN/1,518, returns or replacements are accepted under the following conditions:
1.Quantity discrepancies, incorrect items, or visible external defects (such as breakage or corrosion), acknowledged by Aetrix.
2.The issue is reported within 90 days of delivery.
3.The BGX7220HN/1,518 part is unused and in its original packaging.
Return procedure for BGX7220HN/1,518:
1.Submit a request within 90 days.
2.Obtain a Return Material Authorization (RMA) from Aetrix.
