onsemi DM81LS97AN
- Part No.:
- DM81LS97AN
- Manufacturer:
- onsemi
- Package:
- 20-DIP (0.300", 7.62mm)
- Datasheet:
-
DM81LS97AN.pdf
- Description:
- IC BUF NON-INVERT 5.25V 20DIP
- Quantity:
- Payment:

- Shipping:

Inventory:1,397
Please send an inquiry. Send us your inquiry, and we will respond immediately.
Product details
Overview
DM81LS97AN from Fairchild Semiconductor is a 20-pin PDIP-packaged octal 3-state non-inverting buffer with dual independent enable control (G1 for Y1–Y4, G2 for Y5–Y8), 5 V nominal supply, 15 ns typical propagation delay, and 80 mW typical power dissipation-used in bus interface and data routing applications within industrial control backplanes.
For engineers reviewing the DM81LS97AN datasheet, pinout, applications, or equivalent options, key selection considerations include dual-enable architecture, TTL-compatible input thresholds, 3-state output drive capability (±24 mA), and operation across 0°C to +70°C ambient temperature range.
Technical Context
The DM81LS97AN implements eight independent non-inverting buffers using low-power Schottky TTL technology. Each buffer has two inputs: one data (A1–A8) and one active-low enable (G1/G2), with G1 controlling outputs Y1–Y4 and G2 controlling Y5–Y8.
Outputs enter high-impedance state when either G1 or G2 is HIGH; both must be LOW for enabled operation. Logic behavior follows standard TTL voltage thresholds: VIH ≥ 2.0 V, VIL ≤ 0.8 V, VOH ≥ 2.7 V at IOH = −5.2 mA, VOL ≤ 0.5 V at IOL = 24 mA.
Key Specifications
| Parameter | Value and Actual Design Meaning |
|---|---|
| Supply Voltage | 4.75–5.25 V - ensures compatibility with standard 5 V TTL logic rails and stable operation under ±5% rail variation. |
| Propagation Delay | 15 ns typical (tPLH/tPHL) - enables reliable timing in 33 MHz synchronous bus environments with margin. |
| Output Drive | IOL = 24 mA / IOH = −5.2 mA - supports fan-out of ≥20 LS-TTL loads or direct driving of 50 Ω transmission lines. |
| Enable Architecture | Dual independent active-low enables (G1, G2) - allows partitioned bus control for Y1–Y4 and Y5–Y8 without shared gating. |
| Operating Temperature | 0°C to +70°C - validated for commercial-grade industrial equipment and legacy computing backplanes. |
| Power Dissipation | 80 mW typical - reduces thermal load in dense DIP-based PCB layouts versus standard 74LS devices. |
Pinout & Package
DM81LS97AN is housed in a 20-lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300" wide, with 2.54 mm pitch and through-hole mounting.
| Pin/Terminal | Circuit Role | Design Meaning |
|---|---|---|
| 1, 2, 3, 4, 5, 6, 7, 8 | A1–A8 Data Inputs | TTL-compatible inputs accepting 0.8 V/2.0 V thresholds; directly driven by LS-TTL, HCMOS, or microcontroller GPIO. |
| 9, 10 | G1, G2 Enable Inputs | Active-low controls: G1 enables Y1–Y4; G2 enables Y5–Y8; both must be LOW for output assertion. |
| 11, 13, 14, 15, 16, 17, 18, 19 | Y1–Y8 Outputs | 3-state buffered outputs with ±24 mA drive; Hi-Z when G1 or G2 is HIGH; no bus contention during disable. |
| 12 | GND | Signal reference and return path for all I/O and supply currents. |
| 20 | VCC | +5 V supply connection; decoupling capacitor (0.1 µF) recommended adjacent to pin. |
Key Features
| Feature | Design Value |
|---|---|
| Dual independent 3-state enables | Enables selective activation of upper/lower four outputs-ideal for split-bus arbitration or memory-mapped I/O segmentation. |
| Low-power Schottky TTL process | 80 mW typical dissipation vs. 100+ mW for standard 74LS - lowers board-level thermal density in legacy systems. |
| 15 ns propagation delay | Meets timing budgets for 33 MHz system clocks with setup/hold margin - suitable for ISA-bus and early PCI bridge interfaces. |
| TTL-compatible input/output levels | Direct interoperability with 74LS, 74ALS, and microcontroller GPIO without level-shifting circuitry. |
Applications
| Industrial Backplane Bus Interface | Legacy PC Expansion Slot Buffering |
|---|---|
Use Scenario: Isolating and driving address/data buses between CPU modules and peripheral cards in DIN-rail mounted PLC racks. IC Role / Device Role / Timing Role: Non-inverting octal buffer with dual enable lines provides direction-controlled bus isolation and noise immunity on 8-bit parallel paths. Use Value: Prevents bus contention during card hot-swap via independent G1/G2 control; 24 mA drive sustains signal integrity over 15 cm ribbon cable runs. | Use Scenario: Buffering I/O port signals between ISA bus slots and add-on cards such as serial/parallel interface adapters. IC Role / Device Role / Timing Role: Level-translating and fan-out buffer for 8-bit bidirectional data latches in ISA-compatible designs. Use Value: 15 ns delay meets ISA timing spec; dual enables allow per-slot enable/disable without affecting adjacent card operation. |
| Microcontroller Parallel Port Expansion | Test Equipment Signal Routing Matrix |
Use Scenario: Extending GPIO count of 8-bit MCUs (e.g., 8051 derivatives) to drive external LED arrays, keypad scanners, or relay banks. IC Role / Device Role / Timing Role: Output-expanding buffer with 3-state capability enabling time-multiplexed sharing of common data lines. Use Value: G1/G2 allows dynamic partitioning of 8 outputs into two independently gated groups-reducing external logic count. | Use Scenario: Constructing reconfigurable signal paths in automated test fixtures where multiple DUTs share stimulus/response resources. IC Role / Device Role / Timing Role: Bidirectional bus switch element controlled by test sequencer logic to route analog/digital signals across fixture channels. Use Value: Hi-Z state eliminates crosstalk between unused paths; TTL compatibility simplifies integration with existing digital control boards. |
Equivalent & Alternatives
The following parts are listed as comparable options for similar octal 3-state buffer applications.
| Alternative Part | Technical Difference | Application Difference | Selection Advice |
|---|---|---|---|
| SN74LS244N | Single common enable (not dual); identical 20-pin PDIP package and 15 ns delay. | Lacks independent group control-requires external gating logic for split-enable functionality. | Select when full 8-bit enable suffices and board space permits added discrete logic. |
| 74ACT244PC | CMOS process, 3.3 V/5 V tolerant, 8.5 ns delay, higher IOL (24 mA) but lower IOH (+24 mA). | Not TTL-voltage compatible; requires level translation if interfacing with legacy 5 V LS logic. | Select for new 3.3 V designs needing faster switching and lower static power; avoid in mixed-voltage LS systems. |
Compared with SN74LS244N and 74ACT244PC, the DM81LS97AN uniquely delivers dual independent enables in a drop-in PDIP footprint while maintaining strict LS-TTL voltage compatibility-critical for retrofitting or maintaining legacy industrial hardware without redesign.
Availability
DM81LS97AN is available at Aetrix Electronics and suitable for industrial backplane bus interface, legacy PC expansion slot buffering, and microcontroller parallel port expansion requiring stable component supply and long-term obsolescence management.
Supply support for DM81LS97AN includes scheduled delivery planning, volume procurement assistance, BOM continuity management, traceable sourcing, and lifecycle availability coordination for OEM customers, industrial embedded developers, connected-device designers, and electronics production programs.
Manufacturer
Fairchild Semiconductor was a U.S.-based semiconductor company specializing in analog and discrete power products, acquired by ON Semiconductor in 2016.
The DM81LS97AN belongs to Fairchild's legacy LS-TTL logic family, designed specifically for robust, low-power bus interfacing in commercial-temperature industrial and computing systems.
FAQ
What is the function of G1 and G2 on the DM81LS97AN?
G1 and G2 are active-low enable inputs that independently control two groups of outputs: G1 enables Y1–Y4, and G2 enables Y5–Y8. When either G1 or G2 is HIGH, its associated outputs go to high-impedance (Hi-Z). Both must be LOW for their respective outputs to reflect the A1–A8 inputs. This architecture allows segmented bus control not found in single-enable octal buffers like the SN74LS244N, making the DM81LS97AN especially useful in modular backplane designs where partial bus isolation is required.
Does the DM81LS97AN support 3.3 V logic inputs?
No, the DM81LS97AN is a TTL-family device with input thresholds defined for 5 V operation: VIL ≤ 0.8 V and VVIH ≥ 2.0 V. While it may function with 3.3 V CMOS outputs in some cases, guaranteed switching is only specified across the full 0–5 V range. For reliable 3.3 V interfacing, level-shifting circuitry or a CMOS-compatible alternative such as the 74ACT244PC is recommended. The DM81LS97AN itself requires a 4.75–5.25 V supply and is not 3.3 V tolerant.
What is the maximum output current rating for DM81LS97AN?
The DM81LS97AN specifies IOL = 24 mA (LOW-level output current) and IOH = −5.2 mA (HIGH-level output current) under recommended operating conditions. These values define worst-case drive capability into standard TTL loads and ensure reliable fan-out to ≥20 LS-TTL inputs. Exceeding these ratings risks parametric shift or accelerated wear; sustained short-circuit current is limited to −20 mA to −100 mA per output (per datasheet Note 6), with duration capped at one second.
Can DM81LS97AN replace DM81LS95AN in a design?
Yes, the DM81LS97AN can replace the DM81LS95AN in most applications because both share identical pinout, electrical specifications (15 ns delay, 80 mW power, same DC/AC characteristics), and non-inverting logic function. The key difference is enable architecture: DM81LS95AN uses a single 2-input NOR gate for all eight enables, whereas DM81LS97AN splits enables across G1 (Y1–Y4) and G2 (Y5–Y8). If the original design relies on shared enable control, the DM81LS97AN's dual-enable feature offers enhanced flexibility-but requires verifying that G1 and G2 are tied together or driven identically in the replacement layout.
Is DM81LS97AN RoHS compliant?
The original DM81LS97AN was manufactured prior to RoHS enforcement and uses leaded solder and packaging materials not compliant with EU Directive 2011/65/EU. Aetrix Electronics supplies only legacy-qualified units conforming to original Fairchild specifications, including Pb-containing PDIP packaging. For RoHS-compliant alternatives, consider modern equivalents such as the SN74LVC244A (with appropriate level-shifting), though pinout and voltage compatibility must be verified per application.
DM81LS97AN Specifications
- Product attributes
- Attribute value
- Manufacturer:
- onsemi
- Series:
- 74LS
- Package/Case:
- 20-DIP (0.300", 7.62mm)
- Packaging:
- Tube
- Product Status:
- Obsolete
- Logic Type:
- Buffer, Non-Inverting
- Number of Elements:
- 1
- Number of Bits per Element:
- 8
- Input Type:
- -
- Output Type:
- -
- Current - Output High, Low:
- 5.2mA, 24mA
- Voltage - Supply:
- 4.75V ~ 5.25V
- Operating Temperature:
- 0°C ~ 70°C (TA)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Through Hole
- Supplier Device Package:
- 20-PDIP
