Isocom Components 2004 LTD IS314W
- Part No.:
- IS314W
- Manufacturer:
- Isocom Components 2004 LTD
- Category:
- Isolators - Gate Drivers
- Package:
- 6-SOIC (0.268", 6.80mm Width)
- Datasheet:
-
IS314W.pdf
- Description:
- OPTOISO 5KV 1CH GATE DRIVER 6SO
- Quantity:
- Payment:

- Shipping:

Inventory:1,994
Please send an inquiry. Send us your inquiry, and we will respond immediately.
IS314W Specifications
- Product attributes
- Attribute value
- Manufacturer:
- Isocom Components 2004 LTD
- Series:
- -
- Package/Case:
- 6-SOIC (0.268", 6.80mm Width)
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Technology:
- Optical Coupling
- Number of Channels:
- 1
- Voltage - Isolation:
- 5000Vrms
- Common Mode Transient Immunity (Min):
- 20kV/µs
- Propagation Delay tpLH / tpHL (Max):
- 200ns, 200ns
- Pulse Width Distortion (Max):
- 70ns
- Rise / Fall Time (Typ):
- 35ns, 35ns
- Current - Output High, Low:
- 800mA, 800mA
- Current - Peak Output:
- 1A
- Voltage - Forward (Vf) (Typ):
- 1.37V
- Current - DC Forward (If) (Max):
- 25 mA
- Voltage - Output Supply:
- 10V ~ 30V
- Grade:
- -
- Qualification:
- -
- Operating Temperature:
- -40°C ~ 105°C
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 6-SO Stretched
- Approval Agency:
- -
