FETs, MOSFETs
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | FET Type | Technology | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RS1E130GNTBMOSFET N-CH 30V 13A 8HSOP |
900 | 0.00 |
|
Datasheet |
- | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta) | 4.5V, 10V | 11.7mOhm @ 13A, 10V | 2.5V @ 1mA | 7.9 nC @ 10 V | ±20V | 420 pF @ 15 V | - | 3W (Ta), 22.2W (Tc) | 150°C (TJ) | - | - | Surface Mount | 8-HSOP |
|
BUK9M85-60EXMOSFET N-CH 60V 12.8A LFPAK33 |
470 | 0.00 |
|
Datasheet |
TrenchMOS™ | SOT-1210, 8-LFPAK33 (5-Lead) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 12.8A (Tc) | 5V | 73mOhm @ 5A, 10V | 2.1V @ 1mA | 4.4 nC @ 5 V | ±10V | 434 pF @ 25 V | - | 31W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LFPAK33 |
|
RTQ020N05HZGTRMOSFET N-CH 45V 2A TSMT6 |
171 | 0.00 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 45 V | 2A (Ta) | 2.5V, 4.5V | 190mOhm @ 2A, 4.5V | 1.5V @ 1mA | 2.3 nC @ 4.5 V | ±12V | 150 pF @ 10 V | - | 950mW (Ta) | 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSMT6 (SC-95) |
|
|
BUK9M52-40EXMOSFET N-CH 40V 17.6A LFPAK33 |
663 | 0.00 |
|
Datasheet |
TrenchMOS™ | SOT-1210, 8-LFPAK33 (5-Lead) | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 17.6A (Tj) | 5V, 10V | 40mOhm @ 5A, 10V | 2.1V @ 1mA | 4.5 nC @ 5 V | ±10V | 407 pF @ 25 V | - | 31W | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LFPAK33 |
|
DMP3011SFVW-13MOSFET BVDSS: 25V~30V POWERDI333 |
499 | 0.00 |
|
Datasheet |
- | 8-PowerVDFN | Tape & Reel (TR) | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 19.8A (Ta), 50A (Tc) | 4.5V, 10V | 10mOhm @ 11.5A, 10V | 3V @ 250µA | 46 nC @ 10 V | ±25V | 2380 pF @ 15 V | - | 980mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | POWERDI3333-8 |
|
FDMS0312ASMOSFET N-CH 30V 18A/22A 8PQFN |
798 | 0.00 |
|
Datasheet |
PowerTrench®, SyncFET™ | 8-PowerTDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 18A (Ta), 22A (Tc) | 4.5V, 10V | 5mOhm @ 18A, 10V | 3V @ 1mA | 31 nC @ 10 V | ±20V | 1815 pF @ 15 V | - | 2.5W (Ta), 36W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-PQFN (5x6) |
|
NTMFS6H864NLT1GMOSFET N-CH 80V 7A/22A 5DFN |
662 | 0.00 |
|
Datasheet |
- | 8-PowerTDFN, 5 Leads | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 7A (Ta), 22A (Tc) | 4.5V, 10V | 29mOhm @ 5A, 10V | 2V @ 20µA | 9 nC @ 10 V | ±20V | 431 pF @ 40 V | - | 3.5W (Ta), 33W (Tc) | -55°C ~ 175°C (TJ) | - | - | Surface Mount | 5-DFN (5x6) (8-SOFL) |
|
BUK9Y107-80EXMOSFET N-CH 80V 11.8A LFPAK56 |
90 | 0.00 |
|
Datasheet |
TrenchMOS™ | SC-100, SOT-669 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 11.8A (Tc) | 5V | 98mOhm @ 5A, 10V | 2.1V @ 1mA | 6.2 nC @ 5 V | ±10V | 706 pF @ 25 V | - | 37W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LFPAK56, Power-SO8 |
|
CXDM4060N TR PBFREEMOSFET N-CH 40V 6A SOT-89 |
1,088 | 0.00 |
|
Datasheet |
- | TO-243AA | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 6A (Ta) | 4.5V, 10V | 31mOhm @ 6A, 10V | 3V @ 250µA | 12 nC @ 10 V | 20V | 730 pF @ 20 V | - | 1.2W (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-89 |
|
TK30E06N1,S1XMOSFET N-CH 60V 43A TO220 |
69 | 0.00 |
|
Datasheet |
U-MOSVIII-H | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 43A (Ta) | 10V | 15mOhm @ 15A, 10V | 4V @ 200µA | 16 nC @ 10 V | ±20V | 1050 pF @ 30 V | - | 53W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220 |
|
TK1K0A60F,S4XX35 PB-F POWER MOSFET TRANSISTOR |
67 | 0.00 |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 7.5A (Ta) | 10V | 1Ohm @ 3.8A, 10V | 4V @ 770µA | 24 nC @ 10 V | ±30V | 890 pF @ 300 V | - | 40W (Tc) | 150°C | - | - | Through Hole | TO-220SIS |
|
IPA50R500CEXKSA2MOSFET N-CH 500V 5.4A TO220 |
34 | 0.00 |
|
Datasheet |
CoolMOS™ CE | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 5.4A (Tc) | 13V | 500mOhm @ 2.3A, 13V | 3.5V @ 200µA | 18.7 nC @ 10 V | ±20V | 433 pF @ 100 V | - | 28W (Tc) | -40°C ~ 150°C (TJ) | - | - | Through Hole | PG-TO220-3-FP |
|
|
BUK7Y14-80EXMOSFET N-CH 80V 65A LFPAK56 |
75 | 0.00 |
|
Datasheet |
TrenchMOS™ | SC-100, SOT-669 | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 65A (Tc) | 10V | 14mOhm @ 15A, 10V | 4V @ 1mA | 44.8 nC @ 10 V | ±20V | 3155 pF @ 25 V | - | 147W (Tc) | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | LFPAK56, Power-SO8 |
|
TK3R1A04PL,S4XMOSFET N-CH 40V 82A TO220SIS |
77 | 0.00 |
|
Datasheet |
U-MOSIX-H | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 82A (Tc) | 4.5V, 10V | 3.8mOhm @ 30A, 4.5V | 2.4V @ 500µA | 63.4 nC @ 10 V | ±20V | 4670 pF @ 20 V | - | 36W (Tc) | 175°C (TJ) | - | - | Through Hole | TO-220SIS |
|
|
TK5R3A06PL,S4XX35 PB-F POWER MOSFET TRANSISTOR |
75 | 0.00 |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 56A (Tc) | 4.5V, 10V | 5.3mOhm @ 28A, 10V | 2.5V @ 300µA | 36 nC @ 10 V | ±20V | 2380 pF @ 30 V | - | 36W (Tc) | 175°C | - | - | Through Hole | TO-220SIS |
|
|
TK4R3A06PL,S4XMOSFET N-CH 60V 68A TO220SIS |
54 | 0.00 |
|
Datasheet |
U-MOSIX-H | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 68A (Tc) | 4.5V, 10V | 7.2mOhm @ 15A, 4.5V | 2.5V @ 500µA | 48.2 nC @ 10 V | ±20V | 3280 pF @ 30 V | - | 36W (Tc) | 175°C (TJ) | - | - | Through Hole | TO-220SIS |
|
|
TK650A60F,S4XMOSFET N-CH 600V 11A TO220SIS |
74 | 0.00 |
|
Datasheet |
U-MOSIX | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 11A (Ta) | 10V | 650mOhm @ 5.5A, 10V | 4V @ 1.16mA | 34 nC @ 10 V | ±30V | 1320 pF @ 300 V | - | 45W (Tc) | 150°C | - | - | Through Hole | TO-220SIS |
|
|
TK32A12N1,S4XMOSFET N-CH 120V 32A TO220SIS |
66 | 0.00 |
|
Datasheet |
U-MOSVIII-H | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 120 V | 32A (Tc) | 10V | 13.8mOhm @ 16A, 10V | 4V @ 500µA | 34 nC @ 10 V | ±20V | 2000 pF @ 60 V | - | 30W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220SIS |
|
TK7R4A10PL,S4XX35 PB-F POWER MOSFET TRANSISTOR |
100 | 0.00 |
|
Datasheet |
- | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 50A (Tc) | 4.5V, 10V | 7.4mOhm @ 25A, 10V | 2.5V @ 500µA | 44 nC @ 10 V | ±20V | 2800 pF @ 50 V | - | 42W (Tc) | 175°C | - | - | Through Hole | TO-220SIS |
|
|
TK22E10N1,S1XMOSFET N CH 100V 52A TO220 |
31 | 0.00 |
|
Datasheet |
U-MOSVIII-H | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 52A (Tc) | 10V | 13.8mOhm @ 11A, 10V | 4V @ 300µA | 28 nC @ 10 V | ±20V | 1800 pF @ 50 V | - | 72W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220 |
