Microchip Technology ATA5577M1330C-DDB
- Part No.:
- ATA5577M1330C-DDB
- Manufacturer:
- Microchip Technology
- Category:
- RFID, RF Access, Monitoring ICs
- Package:
- Die
- Datasheet:
-
ATA5577M1330C-DDB.pdf
- Description:
- IC RFID TRANSP 100-150KHZ WAFER
- Quantity:
- Payment:
- Shipping:
Inventory:25,140
Please send an inquiry. Send us your inquiry, and we will respond immediately.
Product details
Overview
ATA5577M1330C-DDB from Microchip Technology is a contactless read/write LF RFID identification IC operating at 125 kHz or 134 kHz, featuring 363-bit EEPROM (11 × 33-bit blocks), load-modulated uplink communication via Coil 1/Coil 2 terminals, and OOK/PIE downlink decoding. It serves as the core transponder IC in animal ID tags, access control tokens, and waste management tags.
For engineers reviewing the ATA5577M1330C-DDB datasheet, ATA5577M1330C-DDB pinout, ATA5577M1330C-DDB application, or ATA5577M1330C-DDB equivalent, key selection criteria include ISO/IEC 11784/11785 configurability, password-protected write access, soft modulation switching for high-Q antenna compatibility, and binary-selectable data rates from RF/2 to RF/128.
Technical Context
The ATA5577M1330C-DDB integrates an analog front end with on-chip rectifier, clock extractor, field gap detector, and switchable resistive load modulator between Coil 1 and Coil 2. Its controller executes blockwise EEPROM read/write, loads Mode and Option registers from EEPROM after POR, and enforces lock-bit protection per 33-bit block.
It supports two operational modes: Basic mode with fixed data rates (RF/8–RF/128) and Extended mode enabling binary-programmable data rates, OTP functionality, inverse data output, and fast downlink (~6 kbps). Configuration is stored in EEPROM Block 0 (mode register) and Block 3, Page 1 (AFE option register), both preprogrammed at delivery.
Key Specifications
| Parameter | Value and Actual Design Meaning |
|---|---|
| Operating Frequency | 125 kHz or 134 kHz - enables interoperability with standard LF RFID readers compliant with ISO/IEC 11784/11785. |
| EEPROM Capacity | 363 bits (11 blocks × 33 bits) - provides 7×32-bit user memory blocks, 2×32-bit unique ID fields, and dedicated configuration/option registers. |
| Data Rate Range | RF/2 to RF/128 (binary-selectable in Extended mode) - supports flexible reader compatibility from low-speed legacy systems to higher-throughput applications. |
| Uplink Modulation | Resistive load modulation between Coil 1 and Coil 2 - enables passive power harvesting and bidirectional communication without external supply. |
| Downlink Protocol | 100% OOK Pulse Interval Encoding (PIE) - decodes reader commands using field gap timing, compatible with T5557/ATA5567 base stations. |
| Memory Protection | Per-block lock bit + password mode (Block 7) - prevents unauthorized writes; lock bits are irreversible once set. |
| Init Delay | ~69 ms when Init Delay bit = 1 - ensures stable power-up sequencing before modulation begins, critical for reliable wake-up in multi-tag environments. |
Pinout & Package
ATA5577M1330C-DDB uses a die-only format with two bond pads: Coil 1 and Coil 2. These terminals serve dual roles - providing RF power harvesting and enabling bidirectional communication via load modulation. No additional supply or ground pins are required.
| Pin/Terminal | Circuit Role | Design Meaning |
|---|---|---|
| Coil 1 | RF Interface Terminal | Connects to one end of external LC antenna coil; participates in rectification, clock extraction, and load modulation. |
| Coil 2 | RF Interface Terminal | Connects to other end of external LC antenna coil; completes resonant tank and enables resistive damping for uplink transmission. |
Key Features
| Feature | Design Value |
|---|---|
| On-chip trimmed capacitor | 250 pF ±3% - reduces external component count and improves tuning stability for 125 kHz operation. |
| Soft modulation switching | Configurable transition ramp - minimizes clock loss and timing violations in high-Q antenna systems. |
| ISO/IEC 11784/11785 compatibility | Configurable via Option register - enables compliance with global animal identification standards without hardware change. |
| Answer-On-Request (AOR) mode | Wake-up via opcode + password - eliminates continuous modulation, extending battery-free tag lifetime in dense-reader environments. |
| OTP functionality | Master key = 6 + OTP bit = 1 locks all blocks permanently - ensures immutable configuration for certified ID applications. |
Applications
| Animal Identification | Access Control Tokens |
|---|---|
Use Scenario: Implantable or ear-tag RFID transponders used in livestock tracking and veterinary certification under ISO/IEC 11784/11785. IC Role / Device Role / Timing Role: Passive transponder IC that powers from reader field, stores unique 40-bit traceability ID, and transmits encrypted ID on demand. Use Value: Factory-programmed traceability data (ACL = E0h, MFC = 15h, CID = 00001b) ensures regulatory compliance and supply-chain auditability. | Use Scenario: Reusable proximity cards or fobs for secure facility entry, requiring tamper-resistant memory and password-protected reprogramming. IC Role / Device Role / Timing Role: Read/write IDIC managing user memory blocks, enforcing password-mode writes, and supporting AOR to prevent eavesdropping during idle periods. Use Value: Blockwise lock bits and 32-bit password memory enable granular access control and secure credential updates in field-deployed devices. |
| Waste Management Tags | Industrial Asset Tracking |
Use Scenario: Ruggedized bin or container tags exposed to moisture, temperature extremes, and mechanical stress in municipal collection systems. IC Role / Device Role / Timing Role: Low-frequency transponder IC with high Q-antenna tolerance and configurable downlink timing to maintain reliability across variable coil coupling conditions. Use Value: Soft modulation switching and adjustable clamp/modulation voltage settings ensure consistent read range despite coil deformation or environmental detuning. | Use Scenario: Tooling or equipment tags in factory automation where metal proximity degrades RF performance and long-term data integrity is mandatory. IC Role / Device Role / Timing Role: EEPROM-based IDIC storing calibration data, maintenance history, and asset IDs with OTP locking to prevent accidental overwrite. Use Value: One-Time-Programmable mode (master key = 6 + OTP = 1) guarantees permanent retention of critical asset identifiers across product lifecycle. |
Equivalent & Alternatives
The following parts are listed as comparable options for similar LF RFID transponder IC applications.
| Alternative Part | Technical Difference | Application Difference | Selection Advice |
|---|---|---|---|
| T5557 | Same 363-bit EEPROM structure and PIE downlink protocol; lacks OTP, soft modulation, and ISO/IEC 11784/11785 configuration bits. | No built-in traceability data structure; requires external logic for AOR or password enforcement. | Choose T5557 only for cost-sensitive legacy systems where extended features are unused. |
| ATA5567 | Pin-compatible predecessor with identical pad layout; missing ATA5577C's enhanced AFE option register and fast downlink capability. | Limited downlink timing flexibility; no factory-programmed traceability ID or ACL/MFC encoding. | Select ATA5567 only if existing designs require drop-in replacement without firmware or configuration updates. |
Compared with T5557 and ATA5567, the ATA5577M1330C-DDB delivers enhanced system-level robustness through factory-traceable IDs, programmable analog front-end tuning, and OTP lockdown-making it suitable for certified animal ID and regulated industrial tagging where data immutability and standard compliance are mandatory.
Availability
ATA5577M1330C-DDB is available at Aetrix Electronics and suitable for animal identification, access control tokens, and waste management systems requiring stable component supply, long-term lifecycle support, and traceable sourcing.
Supply support for ATA5577M1330C-DDB includes scheduled delivery planning, volume procurement assistance, BOM continuity management, traceable sourcing, and lifecycle availability coordination for OEM customers, industrial embedded developers, connected-device designers, and electronics production programs.
Manufacturer
Microchip Technology Inc. is a U.S.-based semiconductor manufacturer specializing in microcontrollers, analog devices, and secure identification solutions.
The ATA5577 family is designed as a next-generation LF RFID transponder IC platform targeting regulatory-compliant animal ID, secure access credentials, and industrial asset tagging with enhanced configurability and factory-traceable data structures.
FAQ
What is the primary function of the ATA5577M1330C-DDB in an RFID system?
The ATA5577M1330C-DDB functions as a passive, contactless read/write identification IC that harvests power from a 125 kHz or 134 kHz reader field and communicates via load modulation between its Coil 1 and Coil 2 terminals. It stores 363 bits of EEPROM data-including user memory, unique ID, and configuration registers-and supports ISO/IEC 11784/11785-compliant animal ID applications. The ATA5577M1330C-DDB replaces legacy devices like T5557 while adding OTP locking and soft modulation for improved reliability.
Does the ATA5577M1330C-DDB require an external power supply or battery?
No, the ATA5577M1330C-DDB operates entirely without external power or battery. It derives its supply voltage from the alternating magnetic field generated by an LF RFID reader through the external antenna coil connected to Coil 1 and Coil 2. On-chip rectification and regulation convert this RF energy into usable DC voltage for internal circuitry and EEPROM programming. This makes the ATA5577M1330C-DDB ideal for maintenance-free, implantable, or disposable RFID tags.
How does the ATA5577M1330C-DDB support ISO/IEC 11784/11785 compliance?
The ATA5577M1330C-DDB supports ISO/IEC 11784/11785 compliance through configurable AFE and modulation parameters stored in its EEPROM Option register (Block 3, Page 1) and Configuration register (Block 0). Factory-programmed traceability data-including Allocation Class (ACL = E0h), Manufacturer Code (MFC = 15h), and Chip ID (CID = 00001b)-are embedded in Blocks 1 and 2 of Page 1 and transmitted upon reader request. The ATA5577M1330C-DDB enables full standard alignment without hardware modification.
What memory protection mechanisms does the ATA5577M1330C-DDB provide?
The ATA5577M1330C-DDB implements three-tiered memory protection: per-block lock bits (1 per 33-bit block), password-protected write access (using Block 7 as 32-bit password memory), and One-Time-Programmable (OTP) mode activated by setting OTP = 1 and master key = 6. Once locked, a block cannot be rewritten via RF field; OTP mode permanently disables all further writes. These features ensure data integrity in regulated applications such as animal ID and secure access control using the ATA5577M1330C-DDB.
Can the ATA5577M1330C-DDB be used with high-Q antennas, and how is compatibility ensured?
Yes, the ATA5577M1330C-DDB is explicitly designed for high-Q antenna compatibility. It achieves this through soft modulation switching-configurable transition ramps that prevent abrupt signal edges-and adjustable AFE parameters (clamping voltage, modulation level, clock/gap detection thresholds) stored in the Option register. These features mitigate clock loss and timing violations common in high-Q systems. The ATA5577M1330C-DDB also includes on-chip 250 pF ±3% trimming capacitance to simplify antenna tuning at 125 kHz.
ATA5577M1330C-DDB Specifications
- Product attributes
- Attribute value
- Manufacturer:
- Microchip Technology
- Series:
- -
- Package/Case:
- Die
- Packaging:
- Bulk
- Product Status:
- Active
- Type:
- RFID Transponder
- Frequency:
- 100kHz ~ 150kHz
- Standards:
- ISO 11784, ISO 11785, ISO 15693
- Interface:
- -
- Voltage - Supply:
- 3.6V
- Operating Temperature:
- -40°C ~ 85°C
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- Wafer
ATA5577M1330C-DDB FAQ
1.How can I place an order for ATA5577M1330C-DDB through Aetrix?
Please submit a Request for Quotation (RFQ) for ATA5577M1330C-DDB on Aetrix. Our sales agent will provide a competitive quotation and guide you through the order confirmation once you accept the terms.
2.Are the price and stock information for ATA5577M1330C-DDB reliable?
The price and inventory of ATA5577M1330C-DDB are updated periodically and may fluctuate due to market conditions. Stock and pricing data are typically refreshed every 24 hours. Quotation validity for ATA5577M1330C-DDB is usually 5 days.
3.What payment methods are accepted for ATA5577M1330C-DDB?
We accept Wire Transfer, PayPal, Credit Card, Western Union, MoneyGram, and Escrow for ATA5577M1330C-DDB transactions.
Note: Certain payment methods may incur a processing fee.
4.How is shipping managed for ATA5577M1330C-DDB?
ATA5577M1330C-DDB orders can be shipped via leading logistics carriers, including DHL, UPS, FedEx, TNT, or Registered Mail.
Once your ATA5577M1330C-DDB order is processed, you will receive an email with the shipment details and tracking number.
Note: Tracking information may take up to 24 hours to appear. Express delivery typically takes 3–5 business days.
5.How can I obtain technical support or documentation for ATA5577M1330C-DDB?
For technical support, including ATA5577M1330C-DDB datasheets, pinout diagrams, or application guidance, please contact our engineering support team. They can provide detailed documentation and assistance for your ATA5577M1330C-DDB requirements.
6.How does Aetrix verify that ATA5577M1330C-DDB is sourced from the original manufacturer or authorized distributors?
All ATA5577M1330C-DDB products on Aetrix are procured from qualified distributors and authorized channels. Our dedicated quality assurance team conducts strict verification, including traceability checks and, if necessary, third-party testing. This ensures that ATA5577M1330C-DDB meets industry standards.
7.What is the process for return or replacement of ATA5577M1330C-DDB?
All ATA5577M1330C-DDB units undergo pre-shipment inspection (PSI). If there is an issue with ATA5577M1330C-DDB, returns or replacements are accepted under the following conditions:
1.Quantity discrepancies, incorrect items, or visible external defects (such as breakage or corrosion), acknowledged by Aetrix.
2.The issue is reported within 90 days of delivery.
3.The ATA5577M1330C-DDB part is unused and in its original packaging.
Return procedure for ATA5577M1330C-DDB:
1.Submit a request within 90 days.
2.Obtain a Return Material Authorization (RMA) from Aetrix.
